Product Specifications

Type Desktop

Maximum size A3

Copy Sizes Cassette; A5R-A3; Stack Bypass: A3-A6, Envelopes

Resolution Scanning 600dpi x 600dpi; Copying 1200dpi equivalent x 600dpi; Printing 2400dpi equivalent x 600dpi 256 Gradations

Copy/Print Speed A4: 22ppm (iR2230), 28 ppm (iR2830)

First Copy Time less than 4.9 sec

Warm-up Time 15 sec max (10 sec max from sleep mode)

Multiple Copies/Prints 1 to 999 prints

Duplexing Standard automatic stack less

Paper Weight Cassette: 64 to 80gsm; Stack Bypass: 64 to 128gsm; Cassette: Universal: A5R to A3

Paper Capacity Standard: 550 Sheets x 2 cassettes (1100 sheets); Multi Stack Bypass: 50 sheets (80gsm); Optional: 550 sheets x 2 cassettes (1100 sheets); Max paper capacity: 2250 sheets

CPU 300 Mhz

Memory128MB (Max: 256MB)

Hard Disk Drive 20 GB (Optional)

Interface Ethernet (100Base-TX/10-Base-T)

Power Supply 230V/6A/50Hz

Dimensions WxDxH : 565 x 700 x 761mm

Weight Approx. 70kg
